Product Introduction
P2020 series non-contact magnetic angle sensor, 0-360° high-precision measurement,
?measurement accuracy 0.088mm, sensor power supply 5-24V DC, output 0-10V, 4-20MA?
or RS485 digital signal, can be used with all kinds of collectors, Digital display meter,
PLC system or computer use
Mechanical parameters:
Dimensions: straight length: 38mm, body height: 33mm
Weight<200g
Maximum speed: 6000RPM
Spindle load: 20N in axial direction, 20N in longitudinal direction
Working temperature:-25 ℃ to + 120 ℃
Storage temperature:-40 ℃ to + 125 ℃
Humidity: 90%RH
Anti-vibration: 10G
Impact resistance: 50G
Voltage range: 5-24VDC
Current: 50MA@12VDC
Power-on time: 100MS
Insulation resistance: >1MΩ
0-10V/4-20MA analog signal output
Range |
Precision |
Range |
Precision |
0-360° |
0.088° |
0-90° |
0.022° |
0-270° |
0.066° |
0-45° |
0.011° |
0-180° |
0.044° |
0-30° |
0.007° |
0-120° |
0.029° |
0-15° |
0.004° |
?
Application:
Various mechanical equipment corner detection, length/height measurement,
?and replacement of various potentiometers and other application fields.
